| Parameter | Specification |
|---|---|
| Model | JNP-QSFP28-100G-SR4 |
| Type | QSFP28 Optical Transceiver |
| Data Rate | 100 Gbps |
| Transmission Distance | Up to 100 meters (using OM4 multimode fiber) |
| Wavelength | 850 nm |
| Interface | MPO/MTP multi-fiber connector |
| Fiber Type | Multimode fiber (MMF) |
| Form Factor | QSFP28 |
| Standards Compliance | IEEE 802.3bm 100GBASE-SR4 |
| Channels / Baud Rate | 4 × 25 Gbps |
| Power Consumption | ≤ 3.5 W |
| Operating Temperature | 0°C ~ 70°C |
| Storage Temperature | -40°C ~ 85°C |
| Modulation | NRZ (Non-Return-to-Zero) |
| Hot-Pluggable | Yes |
Product Advantages
- High-Speed Transmission: Supports 100G data rate for high-bandwidth data center applications.
- Multimode Fiber Support: Works with OM3/OM4 fibers, achieving distances up to 100 meters.
- Low Power Consumption: Maximum power ≤ 3.5 W, energy-efficient.
- Standards Compliance: Fully compliant with IEEE 802.3bm 100GBASE-SR4, ensuring interoperability.
- Hot-Pluggable: Easy maintenance and upgrade without powering down equipment.
- Compact Form Factor: QSFP28 design saves rack space and supports high-density deployment.
