JNP-QSFP28-100G-LR4 Specifications
| Parameter | Description |
|---|---|
| Module Type | QSFP28 100G LR4 Optical Transceiver |
| Data Rate | 100 Gbps |
| Transmission Distance | Up to 10 km (Single-Mode Fiber) |
| Fiber Type | Single-Mode Fiber (SMF) |
| Wavelength | 1310 nm (4 wavelengths CWDM) |
| Connector Type | LC Duplex |
| Supported Protocol | 100G Ethernet |
| Transmit Power | 0 ~ +4 dBm |
| Receiver Sensitivity | ≤ -8.4 dBm |
| Power Consumption | ≤ 5.5 W |
| Operating Temperature | 0°C ~ 70°C |
| Form Factor | Standard QSFP28 |
| Hot Pluggable | Yes |
| Compatibility | Compatible with Juniper and other QSFP28 100G LR4 supported devices |
Key Advantages
- High-Speed Transmission: Supports 100G Ethernet, ideal for core and aggregation layers in data centers.
- Long-Distance Coverage: Single-mode fiber enables transmission up to 10 km, suitable for large-scale data centers and metro networks.
- Wavelength Division Multiplexing: 4 CWDM wavelengths enhance efficiency and reduce fiber usage.
- Low Power Consumption: Maximum power ≤ 5.5 W, energy-efficient design.
- Hot Pluggable: Easy module replacement and maintenance, minimizing network downtime.
- Strong Compatibility: Works with multiple vendors’ devices, flexible deployment in existing network infrastructure.
