Product Specifications
| Parameter | Specification |
|---|---|
| Model | FN-TRAN-GC |
| Type | Optical Transceiver / Module |
| Data Rate | 1 Gbps or 10 Gbps (model dependent) |
| Fiber Type | Single-Mode / Multimode (model dependent) |
| Wavelength | 850 nm / 1310 nm / 1550 nm (model dependent) |
| Maximum Transmission Distance | 100 m ~ 10 km (depending on fiber type and wavelength) |
| Package Type | SFP / SFP+ |
| Connector Type | LC Duplex |
| Transmit Power | -9 ~ 0 dBm (typical, model dependent) |
| Receive Sensitivity | ≤ -18 dBm (typical, model dependent) |
| Standard Compliance | IEEE 802.3 / 802.3u / 802.3z (model dependent) |
| Operating Temperature | 0 ~ 70°C (Commercial) |
| Power Consumption | ≤ 1 W |
| RoHS Compliance | Yes |
Product Advantages
- Multi-Rate Support: Supports 1G/10G data rates, adaptable to different network requirements.
- Flexible Fiber Compatibility: Supports both single-mode and multimode fibers, suitable for short and long-distance connections.
- Energy Efficient: Low power consumption (≤1 W) reduces operational costs.
- Hot-Pluggable Design: Allows easy installation and maintenance without shutting down equipment.
- Strong Standard Compliance: Compatible with IEEE optical module standards, widely supported by switches and servers.
- Reliable Operating Temperature: Operates stably in 0–70°C commercial temperature range.
